iFlight Nazgul XL5 V1.1 Frame Kit including TPU
AU$124.75
The iFlight Nazgul XL5 ECO frame is a 5″ freestyle frame. Made from a super-stiff carbon for minimum resonance and recommended 2207 motors for maximum 5″ prop control. This Frame kit and the Nazgul5 V3 Frame kit are the same Frame kit.
ONLY 4 LEFT
Description
iFlight Nazgul XL5 V1.1 Frame Kit including TPU
The iFlight Nazgul XL5 ECO frame is a 5″ freestyle frame. Made from a super-stiff carbon for minimum resonance and recommended 2207 motors for maximum 5″ prop control. This Frame kit and the Nazgul5 V3 Frame kit are the same Frame kit.
Change log:
- July 19, 2024: Battery Plug mount updated to a fixed form. The frame kit upgraded to V1.1.
- Sept. 10, 2024: Product upgrade, the side panels will be installed by default.
Features
- 5″ version also fits 5.1″ style propellers
- Fits both 30.5×30.5 and 20×20 stacks
- Compatible with DJI O3 HD System
- 5mm arm design for more durability
- Popular True-X configuration
- LED illuminated Logo
- TPU crash-guards
- Easy-Swap arms
Specifications
- Product Name: Nazgul XL5 V1.1 ECO Frame Kit
- Geometry: True-X
- Wheelbase: 245mm
- Frame Dimension: L173*W173*H36.5 mm
- Frame Body Dimension: 33.5mm
- Arm Thickness: 5mm
- Bottom Plate Thickness: 2.5mm
- Top Plate Thickness: 2mm
- Upper Plate Thickness: 3mm
- Max Flight Stack Height: 22mm
- Max VTX Height: 29mm
- Motor Mounting：16x16mm
- VTX Mounting：30.5*30.5 φ3mm / 25*25 φ1.6mm / 20*20 φ2mm
- Weight: 233g (Included no TPU Parts)
Includes
- 1 x Nazgul XL5 V1.1 ECO Frame Kit
- 1 x GoPro TPU Base Mount
- 1 x Screw Bag
- 4 x TPU Armguard
- 1 x Bottom Plate Front Protection TPU
- 1 x Bottom Plate Rear Protection TPU
- 1 x Anti-slip Battery Pad
- 4 x Motor Wire Shield Tube
- 2 x Battery Strap(20*250mm)
Additional information
