SpeedyBee Nano 2.4G ExpressLRS ELRS Receiver
AU$20.75
The SpeedyBee Nano 2.4GHz ExpressLRS Receiver is a compact, lightweight receiver ideal for FPV setups. It operates on a 2.4GHz frequency and features a T-antenna for optimal signal reception.
Sold out
Description
SpeedyBee Nano 2.4G ExpressLRS ELRS Receiver
The SpeedyBee Nano 2.4GHz ExpressLRS Receiver is a compact, lightweight receiver ideal for FPV setups. It operates on a 2.4GHz frequency and features a T-antenna for optimal signal reception. Powered by the SX1280+ESP8285 chip, it delivers up to 120mW of output with a 5V input. With an IPEX1 antenna connector and weighing just 0.7g (excluding the antenna), it is perfect for lightweight builds. It comes pre-loaded with SpeedyBee Nano 2.4GHz RX firmware (v3.3.1). The receiver’s light indicator provides easy-to-read statuses for binding, connectivity, and updates via Wi-Fi.
Specifications
- Model SpeedyBee Nano 2.4GHz RX
- Name ExpressLRS Receiver
- Frequency 2.4Ghz
- Antenna T-antenna (54*78mm, 0.6g)
- Chip SX1280+ESP8285
- Power 100mW (Measured around 120mW)
- Input voltage 5V
- Antenna connector IPEX1
- Weight 0.7 gram(without antenna)
- Dimension 10.4mm*18.4mm
- Default Firmware SpeedyBee Nano 2.4GHz RX 3.3.1
Light indicator
- Double red blinking binding
- Slow red blinking powering up but unlinked, no packages received from the transmitter
- Solid red receiver is connected, with signal received
- Fast red flashing Wi-Fi is turned on, and updating via Wi-Fi is available
Note
- To turn on Wi-Fi, wait for 60 seconds after powering on or long press button for 3 seconds
- Quick to cut off the power 3 times, it enters the binding mode
Manual
